Glass Wool Insulation Board
Glass Wool Insulation Board

Glass Wool Insulation Board

Glass wool insulation board is a flat fiberglass panel for partition walls, suspended ceilings, HVAC rooms, and equipment enclosures.
Common thicknesses range from 25 to 100 mm. Density is selected for the required thermal or acoustic duty, while panel size, facing, and fixing points are taken from the installation drawing.
Send Inquiry

Description



Glass wool insulation board gives a stable, cut-to-size layer across frames and other flat building surfaces. Good results depend on more than nominal thickness: the panels must fit around corners, supports, service openings, and equipment edges without wide gaps. We check the outside dimensions, density, facing option, fixing method, and planned joint treatment before the board is packed for the site.

1 1



Product Parameters



Board property

Declared range or value

Base material

Fiberglass / glass wool board

Thermal conductivity

0.034-0.062 W/(m·K)

Density range

30-110 kg/m³; the certificate model uses 48/64 kg/m³

Certified size

1200 x 600 Customization supported

Reaction to fire

Non-combustible Grade A

Moisture data

Hydrophobicity ≥98%; moisture rate ≤5%

Fiber quality

Average fiber diameter 5-8 μm; slag inclusion ≤0.3%



Project Details



01


For project supply, glass wool insulation board quantities are divided between full panels for open areas and cut sections for perimeter zones, penetrations, and equipment borders.


02


The packing schedule can identify these groups separately and include facing-repair tape or joint material where the drawing calls for it.

1 3



Certifications & Qualifications



product-1190-1682

Because the ordered form is a board, its product conformity file must retain the certificate name Fiberglass Board.

The relevant UDEM Technical Inspection Attestation of Conformity follows EN 13162:2012+A1:2015. It is certificate M.2025.206.C125154 with report TCF-OY20250812-EN-01 and model Xinyafeng/48kg_1200*600*50mm.

The order specification and packing list should show density, thickness, and any facing separately without changing the certified product name.

Company management approvals are FAP25259601QRO for quality (GB/T 19001-2016 / ISO 9001:2015), FAP25259601ERO for environment (GB/T 24001-2016 / ISO 14001:2015), and FAP25259601SRO for occupational health and safety (GB/T 45001-2020 / ISO 45001:2018).

When required, we can supply the certificate image, TDS, MSDS, package photographs, customs documents, and packing list.



FAQ



Q: Which information should be confirmed first?

A: Start with the installation area and panel dimensions, then confirm thickness, density, facing, fastening, and the document requirement.

Q: Is one board thickness suitable for every location?

A: No. Available space, heat flow, acoustic performance, humidity, and any fire requirement affect the thickness choice.

Q: What usually delays site handover?

A: Mixed panel sizes, unclear bundle marks, damaged facing, missing joint materials, or mismatched document names can slow inspection.
