Flexible Duct Fire Wrap
Flexible Duct Fire Wrap

Flexible Duct Fire Wrap

Product form: soft wrap with foil or reinforced facing. flexible duct fire wrap is prepared for smoke exhaust ducts with elbows, flanges, hanger rods, and short offsets.
The product name gives only a rough direction. Size, facing, report name, and the surface it will touch are still checked one by one before the order is arranged. For this item, 30-60 mm common thickness; facing and density by report.
Send Inquiry

Description



Flexible duct fire wrap is made for smoke exhaust ducts with elbows, flanges, hanger rods, and short offsets. It is used where the insulation layer must stay continuous while workers still need access to brackets, covers, labels, or future inspection points. The product should be matched with 30-60 mm common thickness; facing and density by report; then the facing and fixing method are confirmed so the finished surface is not damaged by repeated trimming.

product-540-540



Product Parameters



Parameter

Specification

Material / Core

Aluminum silicate needled blanket with foil or reinforced facing; silicate or calcium silicate fire layer by system

Size

7200 x 610 mm and 3600 x 610 mm common rolls

Thickness

30 mm, 50 mm, 60 mm

Density

96 kg/m³ for aluminum silicate blanket; 120±10 kg/m³ rock wool core where composite board is used

Fire Resistance

1 h, 1.5 h, or 2 h by tested duct wrap system

Thermal Conductivity

Rock wool core ≤0.043 W/(m·K); calcium silicate board ≤0.055 or ≤0.078 W/(m·K) by report

Packing

Roll or carton; packing mark follows size, thickness, and fire-resistance level



Main Applications



01


Flexible duct fire wrap can be placed on main runs, branch areas, or equipment edges when the design needs a continuous layer.


02


For ceiling or duct work, the material should be matched with bracket spacing so the surface does not sag after fixing.


03


For narrow rooms, prepare shorter pieces or smaller rolls when long pieces cannot be moved through the site safely.

066f68df-b94d-4abb-819a-9442e86364c0



Certifications & Qualifications



product-1190-1682

For flexible duct fire wrap, use the aluminum silicate needled blanket certificate when the supplied wrap core and roll size match the order file.

Company system qualifications available in the company document set: Quality Management System Certificate (Certificate No. FAP25259601QRO, GB/T 19001-2016 / ISO 9001:2015), Environment Management System Certificate (Certificate No. FAP25259601ERO, GB/T 24001-2016 / ISO 14001:2015), and Occupation Health And Safety Management System Certificate (Certificate No. FAP25259601SRO, GB/T45001-2020 / ISO 45001:2018).

Product conformity document: UDEM Technical Inspection Attestation of Conformity for Aluminum Silicate Needled Blanket, related standard EN 13162:2012+A1:2015, certificate No. M.2025.206.C125156, report No. TCF-OY20250812-EN-03.

Certificate model shown on the file: Xinyafeng/96kg-3600*610*50mm. The order name must not be changed into a tube, board, or other form unless the document set is confirmed again.

TDS, MSDS, test report copy, packing list, and customs documents can be supplied with the certificate image for this wrap order.



FAQ



Q: Why should joints be checked carefully?

A: Joints are where heat, smoke, sound, or moisture problems usually start. Corners and cut edges need the most attention.

Q: Can flexible duct fire wrap be adjusted by order?

A: Yes. Size, thickness, density or grade, facing, packing mark, and accessory list can be discussed before production.

Q: What should be checked when the goods arrive?

A: Check bundle marks, surface damage, quantity, size, and whether the document name matches the product received.
